ASP Web API

ASP.NET Web API is a framework for building web APIs on top of the .NET Framework. Using ASP.NET Web API you can create a HTTP RESTful services.

HTTP is not just for serving up web pages. It is also a powerful platform for building APIs that expose services and data. HTTP is simple, flexible, and ubiquitous. Almost any platform that you can think of has an HTTP library, so HTTP services can reach a broad range of clients, including browsers, mobile devices, and traditional desktop applications.

Get Started

In Visual Studio create a new project and select "ASP.NET Web application" Under Web templates. (I'm using Visual studio 2015)

Create ASP Web API

On the ASP.NET template screen for .NET 4.6 Select "Web API" this will scaffold everything you need. So go ahead create your first project.

Once Visual Studio has created the project you will have 3 controllers AccountController, HomeController, ValuesController

WEBAPI Default Solution

ValuesController has already been created with sample code for the API.

Run the project in debug mode and in your browser Click the "API" option

http://localhost:*****/help

Will show a list of the API methods available.

With the values Controller we can see the break down of all the API Methods

http://localhost:*****/Help/Api/GET-api-Values

Will show you the break down of the method for Get, the parameters required and response.

Summary

This post covered the very basics of getting started with Web API in .net. We'll bring more posts that build on this post over the next few weeks.

ASP Web API ASP.NET Web API is a framework for building web APIs on top of the .NET Framework. Using ASP.NET Web API you can create a HTTP RESTful services. HTTP is not just for serving up web pages. It is also a powerful platform for building APIs…

Read More

API Testing with Postman

Postman

Postman is a powerful API Testing tool, I've been using it for a while to test the API's I've been creating. It presents you with a friendly GUI for constructing requests and reading responses.

The people behind Postman also offer an add-on package called Jetpacks, which includes some automation tools and, most crucially, a Javascript testing library but the basic use of Postman is free.

Get PostMan on windows it runs as a chrome app.

Postman

The URL is the first thing that you would be setting for a request. Clicking on the URL params button will open up the key-value editor for entering URL parameters.

This allows you to build the request to send.

When you send a request it will display the response from the API

Methods

Postman allows a number of API methods for all your needs.

Changing the method is straightforward. Just select the method from the select control. The request body editor area will change depending on whether the method can have a body attached to it or not.

Request Body

Postman lets you send almost any kind of HTTP request.

Form-Data

multipart/form-data is the default encoding a web form uses to transfer data. This simulates filling a form on a website, and submitting it. The form-data editor lets you set key/value pairs (using the key-value editor) for your data. You can attach files to a key as well.

urlencoded

This encoding is the same as the one used in URL parameters. You just need to enter key/value pairs and Postman will encode the keys and values properly.

raw

A raw request can contain anything. Postman doesn't touch the string entered in the raw editor except replacing environment variables. Whatever you put in the text area gets sent with the request. The raw editor lets you set the formatting type along with the correct header that you should send with the raw body. You can set the Content-Type header manually as well. Normally, you would be sending XML or JSON data here.

binary

binary data allows you to send things which you can not enter in Postman. For example, image, audio or video files. You can send text files as well. As mentioned earlier in the form-data section, you would have to reattach a file if you are loading a request through the history or the collection.

Response

An API response consists of the body, headers and the status code. Postman organizes body and headers in different tabs. The status code with the time taken for the API call is displayed next to the tabs. You can hover over the status code to get more details about the code.

The Postman body tab gives you several tools to help you make sense of things quickly. The body can be viewed in one of three views - pretty, raw, and preview.

Pretty

The pretty mode formats JSON or XML responses so that they are easier to look at. Nobody wants to scroll through a minified single line JSON response looking for that elusive string.

Raw

The raw view is just a big text area with the response body. It can help to tell whether your response is minified or not.

Preview

The preview tab renders the response in a sandboxed iframe. Some web frameworks by default return HTML errors and the preview mode is especially helpful there. Due to iframe sandbox restrictions, Javascript and images are disabled in the iframe.
