Setup Azure Service bus

By James Kenny
3 min read

Table of Contents

What is Azure Service Bus messaging?

Azure Service Bus messaging is an asynchronous messaging cloud platform that enables you to send data between decoupled systems. Azure Service bus is developed and provided by Microsoft.

Azure Service bus is hosted on Azure. There are different types of messaging built into Azure Service bus but for now and the purpose of this post I'm focused solely on Queues and the basic messaging we need to get started.

Pricing

There are 3 pricing levels for Azure Service bus. Each level comes with some added features.

Basic - €0.0422 per million operations

Standard - €8.433/mo for the First 12.5M Operations

  • Next 88M Ops (13M - 100M Ops) / Month €0.6746 per million operations
  • Next 2,400M Ops (100M - 2,500M Ops) / Month €0.4217 per million operations
  • Over 2,501M Ops / Month €0.1687 per million operations

Premium

Daily €18.77 fixed rate per Message Unit

As pointed out above we're focusing on Queues at the moment so I'm ignoring brokered connections and topics for the moment.

All prices for North Europe in EURO for more Azure Service Bus Pricing

Get Started

To get started we need to go to Azure Portal

On the left click new and search for "Service Bus" this will open the market place and let you select Service bus
Create Azure Service Bus

Select Service Bus, and then select Create.

Next we need to give it a name and resource group and stuff.

Define Service Bus

Select a name, Subscription and then Set the resource group to use an existing or to create a new one.

Also select the pricing tier you want to use.

And hit Create.

That's it your service bus is now being setup for use.

Service Bus up and running

Setup the Queue and access keys

So now we have our service bus created we need to create the queue. Under General select Queues

Create queue

Select Add Queue, and give it a name.

Create queue

We need to get the access keys so we can use the queue. Above queue select "Shared Access Policies" after a second a default "RootManageSharedAccessKey" will appear,

Open the "RootManageSharedAccessKey"

Azure Shared access keys

These keys you will need next so we can use this service bus queue.

Last Update: August 21, 2018
